WT-40
UHF Animal Electronic Ear Tag
• Ear tags are one of animal signs, used to prove the identity of livestock and carry individual information of livestock. The ear tag consists of two parts: the main tag and the auxiliary tag; the back of the main tag's ear tag face is connected to the ear tag neck.
• Attaching electronic tags to pigs’ ears is like giving them an electronic ID card (identity card). The chip in the electronic animal ID card records all the important information of the animal in detail, which is very convenient.
• The ear tag is non-toxic, non-odor, non-irritating, non-polluting thermoplastic polyurethane elastomer (TPU), effectively preventing organic acid, salt water, mineral acid, and ultraviolet radiation.
- Product features
- Specification
- Application
◆ Dimensions: Φ30 × 13.3 mm
◆ Operating Frequency: 860MHz - 960MHz (Customizable)
◆ Air Interface Protocol: EPCglobal Class 1 Gen 2（ISO 18000-6C）
◆ It has no fading, high temperature resistance, cold resistance, softness and durability, no aging, no breakage, no poison, no peculiar smell, no pollution and so on.
◆ Polyurethane material, prevent allergic reaction from animal contact for a long time, anti-bite structure, not easy to fall off.
◆ Superior resistance to harsh environmental impacts.
◆Small and light, easy to carry. It has a long service life and can work at high and low temperatures.
◆ To meet the different needs of customers, we can provide personalized choices, including surface printing electronic codes, patterns and text.
Product Model
|
|
WT-40
|
Operating Frequency
|
|
860MHz - 960MHz
|
Air Interface Protocol
|
|
EPCglobal Class 1 Gen 2（ISO
18000-6C）
|
Dimensions
|
|
Male Φ30 × 23mm，Female Φ30 ×
15MM
|
Memory
|
|
H3，96bit EPC + 512bit
|
Tag Materials
|
|
TPU
|
Applicable Surface Materials
|
|
Animal
|
Read Distance
|
|
>2m （Depends on the reader
and antenna）
|
|
|
|
Laser engraving
|
|
Personalization Options
|
|
Customer specific printing
|
|
|
Printing with variable data
|
Operating Temperature
|
|
-30℃ ~ +60℃
|
Ambient Temperature
|
|
-40℃ ~ +80℃
|
Installation Method
|
|
Insert
|
Weight
|
|
8.5g
|
