Product Model
|
|
WH-198
|
Performance
|
|
|
Operating System
|
|
Android 6.0
|
CPU
|
|
Quad-core Cortex-A17 / 1.8GHz
|
GPU
|
|
ARM Mali-T764 / High performance 3D engine
|
RAM+ROM
|
|
2G+32G / 4G+64 (Optional)
|
Physical Characteristics
|
|
|
|
Dimensions
|
|
167 × 82 × 129mm
|
|
|
Grip 111 × 38 × 47mm
|
Weigh
|
|
575g (battery included/standard
version)
|
Display
|
|
5.0 inches / 1280 × 720 / IPS/180° view
angle
|
|
Touch Screen
|
|
1.1mm thickness tempered glass / 10- dot
touch /
|
|
|
operable with gloves
|
Hotswapping Battery
|
|
Pistol style hotswapping battery
system
|
|
|
|
Power / Volume:3 ALPS buttons / Operating
force 2.5N /
|
|
Buttons
|
|
Operating life 1 million cycles
|
|
|
|
Scan Trigger:OMRON button / Operating
force 1.27N /
|
|
|
Operating life 10 million cycles
|
Power
|
|
6000mAh chargeable Ii-polymer battery
|
Expansion Slot
|
|
Micro SIM card slot*1 / TF card slot*1
|
USB Interface
|
|
Micro USB/MOLEX connector/Operating life
10,000 cycles
|
Audio
|
|
Supported
|
Vibration
|
|
10mm / Button style
|
Charge Indicator
|
|
Bicolor LED
|
Communication
|
|
|
WIFI
|
|
IEEE802.11b / g / n
|
Bluetooth 4.0
|
|
Bluetooth 4.0
|
GNSS
|
|
GPS + GLONASS
|
4G
|
|
Supported
|
Barcode Scanning
|
|
(Optional)
|
1D Linear Scanner
|
|
(Optional)
|
|
|
|
UPC / EA Symbol
SE955N / Code128 / Code39 / Code93 /
|
|
1D Symbologies
|
|
Code11 / Interleaved
2 of 5 / Discrete 2 of 5 /
|
|
|
Chinese 2 of 5 /
Codabar / MSI / RSS etc.
|
2D Linear Scanner
|
|
(Optional)
|
|
2D Symbologies
|
|
Data Matrix / QR Code / Aztec
Code / PDF417 /
|
|
|
US Planet / UK Postal etc.
|
UHF RFID
|
|
(Optional)
|
Engine
|
|
Rodinbell M-2600 / based on Impinj Indy
R2000
|
Protocol
|
|
EPCglobal Class 1 Gen 2/ ISO 18000-6C/6B
|
Frequency
|
|
865MHz - 868MHz / 902MHz - 928MHz
|
Output Power
|
|
0 - 33dbm
|
Peak Inventory Speed
|
|
>500pcs/s
|
UHF Antenna
|
|
4dBi Circular Polarization antenna
|
Read Distance
|
|
>10m
|
|
|
|
China, Korea, Malaysia, Japan
|
|
Supported Regions
|
|
US, Canada and other regions following
U.S. FCC
|
|
|
Europe and other regions following ETSI EN
302 208
|
Graphic Collections
|
|
|
Camera
|
|
13 megapixels /
automatic focus / flashlight
|
User Environment
|
|
|
Operating Temp
|
|
-20℃ to +60℃
|
Storage Temp
|
|
-30℃ to +70℃
|
Humidity
|
|
5% RH - 95% RH non condensing
|
Drop Specification
|
|
1.6 m / 5.25ft
|
Protection Grade
|
|
IP64
|
Developing Environment
|
|
|
SDK
|
|
Software Development
Kit
|
